High-performance and robust spindle system meets the most challenging modern processing needs of a wide range of metal materials

The spindle unit is particularly efficient, highly flexible and robust, perfect for universal use. BT/SK/CAT 40 standard taper gives the tool greater stability and balance at high speeds, higher level of static stiffness, ensures the machining precision.

Casting iron bed with strong shock absorption capacity and high physical stability

The casting iron machine bed undergoes a perfect heat treatment process to eliminate residual stress, with sufficient reinforcement plates and three rows of supporting feet ensures the rigidity.

Top-class numerical control system with high processing stability

Intensified moving column structure brings higher rigidity and higher precision

The intensified moving column structure, together with the increased contact surface of the rail and slide block, reduces the deformation of the X-axis, and ensures the high rigidity and precision machining of the machine tool.

The tool magazine moves along with machining process

This saves the dry running time during tool changing, combined with the tool-preparation function, greatly improves the speed of tool change, the tool-to-tool time takes only 2 seconds, which truly brings the high productivity.

BASIC INFORMATION

The machine integrates the function of milling, drilling and tapping
Machining for various length of metal profile, such as aluminum, steel, copper and non-metal materials.
Widely used in industries of rail transportation, aerospace, military machinery, liner module guide rail and etc.

CONFIGURATION

STANDARD


Chip conveyor	Lubrication system	All around protection

OPTIONAL

Category	Items	Unit	PYC – CNC2500
Travel	X – axis	mm	450
	Y – axis	mm	2500
	Z – axis	mm	580
	Distance from spindle nose to table surface	mm	130 – 580
Worktable	Size (Length * Width)	mm	410×650
	Max. load	kg/m²	1500
	T – slot (Number/Width/Center distance)	mm	6/18/100
Spindle	Type	/	Mechanical
	Power	kW	11/13
	Max. speed	rpm	10000
	Taper	/	BT/SK/CAT40 (150 outer diameter)
Feedrates	Rapid on X/Y/Z	m/min	60/28/28
	X/Y/Z Cutting Feed Rate	m/min	15
Tool Magazine	Type	/
	Capacity	pcs.	24
	Tool – to – tool time	sec	2
Dimension	Machine Height	mm	3100
	Covering Area	mm	6900×3100
	Machine Weight	kg	12000
