300A high-strength dense-baked casting, integral casting bed body.
NC intelligent tailstock: Servo-integrated programmable tailstock, with programmable control of tailstock thrust, position, and speed. MT4 and MT5 sleeve specifications.
Permanent magnet synchronous motorized spindle: High-precision and high-rigidity built-in permanent magnet synchronous motorized spindle, with spindle specifications of A2-6, A2-8, and A2-11.
X and Y axis system: Column – mobile structure, large – stroke and high – rigidity straight Y – axis design.
Power turret: 12/15 stations are optional. It is a high-rigidity and high-torque output power turret, with BMT55, BMT65, and BMT75 power tool holder specifications.
td {white-space:nowrap;border:0.5pt solid #dee0e3;font-size:10pt;font-style:normal;font-weight:normal;vertical-align:middle;word-break:normal;word-wrap:normal;}
| Model | TF35 | TF45 | TF55 | TF65 | Unit |
| Spindle taper (main/auxiliary) | A2-5/A2-5 | A2-6/A2-6 | A2-8/A2-8 | A2-11/A2-11 | JIS |
| Standard chuck size (main/auxiliary) | 6/6 | 8/8 | 10/10 | 12/12 | “ |
| Maximum spindle speed (main/auxiliary) | 6000/6000 | 4500/4500 | 3000/3000 | 1000/1000 | rpm |
| Spindle power (main) | 11/15 | 15/18.5 | 30/37 | 30/45 | kw |
| Spindle power (auxiliary) | 11/15 | 15/18.5 | 30/37 | 30/45 | kw |
| Maximum machining diameter | ∅280 | ∅370 | ∅450 | ∅600 | mm |
| Maximum machining length | 400 | 550 | 750 | 850 | mm |
| Number of tools | 12 | 12 | 12 | 12 | pcs |
| Tool specification | □25/∅40 | □25/∅50 | □25/∅50 | □32/∅60 | mm |
| Power turret specification | BMT55 | BMT65 | BMT65 | BMT75 | |
| The maximum machining length among the above parameters is the standard configuration option. | |||||
